性液影院亚洲日韩_兔子先生第一季直击现场是哪一集_国产网红无码福利在线播放_精品老司机综合av丁香_欧美操逼视频_无码高潮喷吹在线观看_三级中文在线观看亚洲_中文字幕乱交人妻_中文字幕精品无码三區_欧美一区二区三区老妇

Home
Hot Line:0086-157-5323-3162
PRODUCTS

Aofeng Single Component, Polyurethane Sealant


Product Description

Aofeng Polyurethane Sealant is a high performance, single component, moisture curing, polyurethane sealant ideally suited for a number of construction applications.


Used to Seal

? Vertical and horizontal expansion joints

? Concrete control joints

? Precast and tilt-up construction

? Masonry expansion joints

? Aluminum curtain walls and storefronts

? Doors and windows

? Submerged applications


Advantages

? Faster curing than most competitive products

? Tack-free in 60 minutes per ASTM C679

? Joint movement capability ±25%

? No priming required for most applications

? Excellent weather resistance

? Non-staining

? No mixing required

? Low VOC – 35.1 g/l

? Paintable after Tack-free

? Low modulus/Low shore A hardness


Colors

Only black currently.


Packaging

Sausage packs only.


Technical Data

Properties Item No. of PU adhesive sealant
QAS QCS JCS-B JCS-G JCS-W JCS-C
Appearance Bright black uniform paste Matt black uniform paste Bright black uniform paste Grey uniform paste White uniform paste Light yellow transparent uniform paste
Density @ 23, g/cm3 1.22±0.02 1.47±0.02 1.45±0.02 1.35±0.02 1.35±0.02 1.20±0.02
Denseness, mm 7.7±0.1 5.7±0.1 8.3±0.1 8.0±0.1 8.0±0.1 8.0±0.1
Hardness Shore A 47±1 85±1 68±1 60±1 60±1 38±1
Extrusion rate, g/min 200 50±2 200 200 200 200
Sag rate, @ 23, mm 0-1.0 0 0-1.0 0-1.0 0-1.0 0
Tack-free time @ 23, 50%, min 30 30 30 30 30 30
Curing rate, mm/24h 3.0-4.0 3.0-4.0 3.0-4.0 3.0-4.0 3.0-4.0 3.0-4.0
Peel adhesion,Cohesion destruction, %  70 70 70 90 90 90
Elongation to break @ 23, 50%rlf, 24h, 2mm), % 900±50 700±30 700±30 350±30 350±30 350±30
Tensile stength @23, 50%rlf, 24h, 2mm, Mpa 4.8±0.2 3.3±0.2 3.0±0.2 3.0±0.2 3.0±0.2 3.0±0.2
Tear strength @ 23, 50%rlf, 24h, 2mm, Kn/m 20±1 20±1 20±1 10±1 10±1 10±1


Storage

Polyurethane sealants and adhesive sealants must be stored in a controlled environment to maximize shelf life. Store the products in the original unopened containers below 77°F (25C).


Shelf Life

When stored at recommended conditions, the shelf life is 6 months after shipment from AOFENG.


Directions for Use

Surface Preparation: Surfaces to be sealed or bonded should be clean and dry. Surfaces should be free from grease, mold release, oil, water/condensation, frost, and other contaminants that may affect the adhesion of the sealant.

Primer: For most applications, high strength bonds can be achieved without the use of a primer. Pre-testing for adhesion is suggested to determine if a primer is needed.


Application: Loading the applicator gun: make sure the applicator is set up with correct plunger attachment for cartridge or sausage pack.


1. Cartridge: Puncture seal in nozzle and remove the pull-tab seal at the bottom of the cartridge. Load into applicator and fix retaining ring (if applicable). Assemble the nozzle (if applicable) and cut to desired size and shape.


2. Sausage Pack: Make a 1" slit close to the crimp on one end of the sausage pack. Load the sausage pack into the applicator barrel (slit side out). Place the rounded end of the supplied sausage nozzle onto the slit end of the sausage package and fix with retaining ring. Cut nozzle to desired size and shape. Product should be used within 24 hours after seal is punctured. Dispense product with the nozzle tip in contact with the substrate to insure good gap filling. Bonding must occur within the first 50% of published skin time.


Do not apply polyurethane sealants and adhesive sealants on frozen nor wet surfaces. Do not apply over silicone nor in the presence of curing silicone nor hybrid products. Avoid contact with alcohol and solvents during curing. Sealant can be tooled immediately after applying to give desired appearance.

Cleanup: While sealant is still soft, cleaning can be done with the same solvents used for surface preparation. Avoid cleaning with alcohol as it will interfere with the curing process. If sealant is already cured, removal is done mechanically with razor knife, piano wire, sanding, etc.





Hottel:0086-157-5323-3162
Addr:Henan Province,China          魯ICP備13018670號
